How to Measure for a Steering Cable


When replacing your steering cable, it's best to remove and measure your old cable before ordering the replacement. If measuring your existing cable isn’t possible, follow our guidelines below.

Measuring Steering Cable

Measure as indicated along intended cable routing:

A = Gunwale to Centerline of cable connection
B = Length along Gunwale
C = Centerline of Wheel to Gunwale

Tilt Tube Mounting

A + B + 6" = Total Measurement
Round the total measurement off to the next full foot.

Example:
A(18") + B(90") + C(24") + 6" = 138" or 11'6" (Round off to 12 ft)

Transom Support Mounting/Splashwell Mounting/Stringer Support Mounting

A + B + C + 6" = Total Measurement

Example:
A(18") + B(90") + C(24") + 6" = 138" or 11'6" (Round off to 12 ft)

Use this measurement to select your new control cable. If you have any questions along the way, feel free to speak with one of our technical representatives at:
1-888-OVERTON (1-888-683-7866).
